Super – 35mm Sliding Windows

Introducing our 35mm Sliding Window System – a fusion of design and durability that empowers you to shape spaces according to your unique vision and lifestyle. This bespoke series stands as a testament to precision engineering, catering to those seeking unmatched strength and refined aesthetics for their windows.

The 35mm Series is meticulously crafted with a focus on strength, making it an ideal choice for windows with larger opening sizes. Its robust design ensures enhanced durability and stability, promising a window system that endures the test of time. With each panel expertly designed and meticulously manufactured, this series offers a perfect blend of elegance and functionality.

Experience the freedom to amplify natural light and ventilation with larger glass panels while reveling in the added strength that this series provides. The 35mm Sliding Window System not only transcends the boundaries of conventional design but also enhances the overall architectural aesthetics of your space.

At Hatimee Glass, we understand that windows are more than just openings – they are expressions of your lifestyle. Elevate your living environment with the superior strength and design versatility of our 35mm Sliding Window System, where innovation meets resilience to create a window solution that truly stands apart.

Super – 35mm Features

Salient Features

  • Premium Quality Aluminium Profile
  • European Design
  • Maximum View Window with just 25mm Slim Centre Profile
  • Suitable for Medium / Large Size Windows
  • Reinforcement Profiles Available for Larger Openings
  • Available in Anodized, Powder Coating and Wooden Finishes.
  • Alloy 6063-T6 Temper as per IS-6477 1983 for dimensional tolerance and IS-1285 1975 for chemical composition and mechanical properties.
  • Unique Sealing to protect from Noise and Dust – Photo with Sashes interlocking with rubber gasket and wool pile.
  • Anti Lift Plugs and Anti Burglary Locks for extra security.
  • Custom Engineered rollers for smooth operations.
  • Special Drainage Solution to keep out heavy rains.
  • Robust, highly Stable can bear wind load upto 2.8 KPA for 32mm window

Technical Characteristics

  • Sash Height (Max) – 3100mm
  • Sash Width (Max) – 2400mm
  • Shutter Dimensions –35mm x 75mm
  • Interlocking Visible Face Width – Non Slim Interlock – 25mm
  • Corner Joints -
    Track Joint – 45 degrees
    Non Slim All Sash Joint – 45 degrees
    Slim Interlock Joionts – 90 degrees
  • Glass Range –
    5mm to 8mm SGU
    18mm to 24mm DGU
  • Roller Width Capacity (2 pcs)
    Fix Single Roller – 85 kgs / sash
    Fix Double Roller – 125 kgs / sash
    Adjustable Double Roller – 200 Kgs / sash
  • Locking Type – Multipoint & Single Point Locking
